Back Up Alarm | 97dB | 51008
This self-grounding back up alarm is rated for 97dB.
Features & Benefits
- Self-grounding
- Steam cleanable
- Epoxy encapsulated solid state electronics
Specifications
SKUs/Accessories Available
This self-grounding back up alarm is rated for 97dB.
Operating Voltage: 12 – 24Vdc
Temperature Range: -30°C to +55°C
Weight: 8.0oz (226g)
Housing: Fiberglass Filled Nylon
Connection: Connect Positive Wire with #8 Ring Terminal to Top Stud | Connect Ground Wire with #8 Ring Terminal to Bottom Stud
Polarity: Reverse Voltage Protected
Mounting: Horizontal or Vertical
Compliance: SAE / DOT
Part # | Decibel Rating at 4' | Operating Voltage |
---|---|---|
51008 | 97dB | 12 - 24Vdc |
